Cornell Dubilier Electronics (CDE)
CAP ALUM 470UF 20% 100V RADIAL
SEK471M100ST is a Aluminum Electrolytic Capacitors manufactured by Cornell Dubilier Electronics (CDE). CAP ALUM 470UF 20% 100V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 100 V, package / case Radial, Can.
In Stock: 3,329
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 470 µF |
| Tolerance | ±20% |
| Voltage - Rated | 100 V |
| ESR (Equivalent Series Resistance) | 280mOhm @ 120Hz |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 875 mA @ 120 Hz |
| Ripple Current @ High Frequency | 1.225 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.295" (7.50mm) |
| Size / Dimension | 0.630" Dia (16.00mm) |
| Height - Seated (Max) | 1.260" (32.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MAL211848471E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 470UF 20% 63V T/H | 78% | View |
| MAL214650471E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 470UF 20% 35V RADIAL | 71% | View |
| EEU-FC1E471LJ | Panasonic Electronic Components | CAP ALUM 470UF 20% 25V RADIAL | 66% | View |
| RJA471M1HBK-1320S | SURGE | CAP ALUM 470UF 20% 50V RADIAL | 59% | View |
| MAL226066471E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 470UF 20% 25V RADIAL | 58% | View |
| 50PX470MEFC10X20 | Rubycon | CAP ALUM 470UF 20% 50V RADIAL | 57% | View |
