Cornell Dubilier Electronics (CDE)
CAP ALUM 1000UF 20% 63V RADIAL
SEK102M063ST is a Aluminum Electrolytic Capacitors manufactured by Cornell Dubilier Electronics (CDE). CAP ALUM 1000UF 20% 63V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 63 V, package / case Radial, Can.
In Stock: 6,550
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 1000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 63 V |
| ESR (Equivalent Series Resistance) | 130mOhm @ 120Hz |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.2 A @ 120 Hz |
| Ripple Current @ High Frequency | 1.68 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.295" (7.50mm) |
| Size / Dimension | 0.630" Dia (16.00mm) |
| Height - Seated (Max) | 1.260" (32.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 50PX1000MEFC12.5X25 | Rubycon | CAP ALUM 1000UF 20% 50V RADIAL | 83% | View |
| RXK102M1VBK-1620S | SURGE | CAP ALUM 1000UF 20% 35V RADIAL | 78% | View |
| UPA1C102MPD1TD | Nichicon | CAP ALUM 1000UF 20% 16V RADIAL | 66% | View |
| EEU-FC1C102S | Panasonic Electronic Components | CAP ALUM 1000UF 20% 16V RADIAL | 65% | View |
| MAL226051102E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 1000UF 20% 50V RADIAL | 60% | View |
| ELXV100ELL102MJ20S | United Chemi-Con | CAP ALUM 1000UF 20% 10V RADIAL | 56% | View |
Submit your RFQ for SEK102M063ST and get a quote within 24 hours.
