Cornell Dubilier Electronics (CDE)
CAP ALUM 360UF 20% 150V FLATPACK
MLSG361M150EK1A is a Aluminum Electrolytic Capacitors manufactured by Cornell Dubilier Electronics (CDE). CAP ALUM 360UF 20% 150V FLATPACK. Key specifications: mounting type Chassis Mount, operating temperature -55°C ~ 125°C, voltage - rated 150 V, package / case FlatPack, Tabbed.
In Stock: 6,205
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 360 µF |
| Tolerance | ±20% |
| Voltage - Rated | 150 V |
| ESR (Equivalent Series Resistance) | 388mOhm @ 120Hz |
| Lifetime @ Temp. | 5000 Hrs @ 125°C |
| Operating Temperature | -55°C ~ 125°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 5.1 A @ 120 Hz |
| Ripple Current @ High Frequency | 6.4 A @ 20 kHz |
| Impedance | - |
| Lead Spacing | 1.000" (25.40mm) |
| Size / Dimension | 1.500" L x 1.750" W (38.10mm x 44.45mm) |
| Height - Seated (Max) | 0.500" (12.70mm) |
| Surface Mount Land Size | - |
| Mounting Type | Chassis Mount |
| Package / Case | FlatPack, Tabbed |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MLS401M150EK1A | Cornell Dubilier Electronics (CDE) | CAP ALUM 400UF 20% 150V FLATPACK | 96% | View |
| MLS401M150EK1D | Cornell Dubilier Electronics (CDE) | CAP ALUM 400UF 20% 150V FLATPACK | 96% | View |
| MLS331M200EK1A | Cornell Dubilier Electronics (CDE) | CAP ALUM 330UF 20% 200V FLATPACK | 86% | View |
| HVMLS331M200EK1D | Cornell Dubilier Electronics (CDE) | CAP ALUM 330UF 20% 200V FLATPACK | 86% | View |
| HVMLS331M200EK0A | Cornell Dubilier Electronics (CDE) | CAP ALUM 330UF 20% 200V FLATPACK | 86% | View |
| HVMLS331M250EA1A | Cornell Dubilier Electronics (CDE) | CAP ALUM 330UF 20% 250V FLATPACK | 80% | View |
