Cornell Dubilier Electronics (CDE)
CAP ALUM 4700UF 20% 16V SNAP
LPW472M1CO25V-W is a Aluminum Electrolytic Capacitors manufactured by Cornell Dubilier Electronics (CDE). CAP ALUM 4700UF 20% 16V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 85°C, voltage - rated 16 V, package / case Radial, Can - Snap-In.
In Stock: 3,773
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 4700 µF |
| Tolerance | ±20% |
| Voltage - Rated | 16 V |
| ESR (Equivalent Series Resistance) | 141mOhm @ 120Hz |
| Lifetime @ Temp. | 1000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.21 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.431 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.984" Dia (25.00mm) |
| Height - Seated (Max) | 0.984" (25.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
LPW472M1CO25V-W is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| UVZ1C472MHD | Nichicon | CAP ALUM 4700UF 20% 16V RADIAL | 82% | View |
| 10YXH4700MEFC12.5X35 | Rubycon | CAP ALUM 4700UF 20% 10V RAD TH | 79% | View |
| EKMG250ELL472MLN3S | United Chemi-Con | CAP ALUM 4700UF 20% 25V RADIAL | 74% | View |
| UVZ1J472MRD | Nichicon | CAP ALUM 4700UF 20% 63V RADIAL | 73% | View |
| 6.3YXJ4700M12.5X25 | Rubycon | CAP ALUM 4700UF 20% 6.3V RADIAL | 72% | View |
| 80MXG4700MEFCSN25X50 | Rubycon | CAP ALUM 4700UF 20% 80V SNAP | 58% | View |
Submit your RFQ for LPW472M1CO25V-W and get a quote within 24 hours.
