Cornell Dubilier Electronics (CDE)
CAP ALUM 560UF 20% 250V SNAP
LP561M250H3P3 is a Aluminum Electrolytic Capacitors manufactured by Cornell Dubilier Electronics (CDE). CAP ALUM 560UF 20% 250V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 250 V, package / case Radial, Can - Snap-In.
In Stock: 7,693
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 560 µF |
| Tolerance | ±20% |
| Voltage - Rated | 250 V |
| ESR (Equivalent Series Resistance) | 347mOhm @ 120Hz |
| Lifetime @ Temp. | 1000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.8 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.52 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 1.181" (30.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| B43255A4567M | EPCOS - TDK Electronics | CAP ALUM 560UF 20% 350V SNAP | 81% | View |
| 381LQ561M180H042 | Cornell Dubilier Electronics (CDE) | CAP ALUM 560UF 20% 180V SNAP | 81% | View |
| B43525A4567M000 | EPCOS - TDK Electronics | CAP ALUM 560UF 20% 350V RADIAL | 78% | View |
| 100ZLH560MEFC16X35.5 | Rubycon | CAP ALUM 560UF 20% 100V RADIAL | 73% | View |
| B43642B9567M000 | EPCOS - TDK Electronics | CAP ALUM 560UF 20% 400V SNAP | 73% | View |
| 860080678020 | Würth Elektronik | CAP ALUM 560UF 20% 50V RADIAL | 66% | View |
Submit your RFQ for LP561M250H3P3 and get a quote within 24 hours.
