Cornell Dubilier Electronics (CDE)
CAP ALUM 4000UF 450V SCREW
HES402G450X5L is a Aluminum Electrolytic Capacitors manufactured by Cornell Dubilier Electronics (CDE). CAP ALUM 4000UF 450V SCREW. Key specifications: mounting type Chassis Mount, operating temperature -40°C ~ 105°C, voltage - rated 450 V, package / case Radial, Can - Screw Terminals.
In Stock: 7,206
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 4000 µF |
| Tolerance | 0%, +50% |
| Voltage - Rated | 450 V |
| ESR (Equivalent Series Resistance) | 25mOhm @ 120Hz |
| Lifetime @ Temp. | 1000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 12.7 A @ 120 Hz |
| Ripple Current @ High Frequency | 15.621 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | - |
| Size / Dimension | 3.000" Dia (76.20mm) |
| Height - Seated (Max) | 5.625" (142.88mm) |
| Surface Mount Land Size | - |
| Mounting Type | Chassis Mount |
| Package / Case | Radial, Can - Screw Terminals |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 550C402T450DP2D | Cornell Dubilier Electronics (CDE) | CAP ALUM 4000UF 450V SCREW | 100% | View |
| LNU2H392MSEJBN | Nichicon | CAP ALUM 3900UF 20% 500V SCREW | 93% | View |
| LNU2H392MSEHBN | Nichicon | CAP ALUM 3900UF 20% 500V SCREW | 93% | View |
| 550392T400DE2B | Cornell Dubilier Electronics (CDE) | CAP ALUM 3900UF 400V SCREW | 90% | View |
| CGR412T075U4C | Cornell Dubilier Electronics (CDE) | CAP ALUM 4100UF 75V SCREW | 69% | View |
| 550C402T450DP2B | Cornell Dubilier Electronics (CDE) | CAP ALUM 4000UF 450V SCREW | 67% | View |
Submit your RFQ for HES402G450X5L and get a quote within 24 hours.
