Cornell Dubilier Electronics (CDE)
CAP ALUM POLY 390UF 20% 2V SMD
ESRE391M02XB is a Aluminum - Polymer Capacitors manufactured by Cornell Dubilier Electronics (CDE). CAP ALUM POLY 390UF 20% 2V SMD. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 105°C, voltage - rated 2 V, package / case 2917 (7343 Metric).
In Stock: 5,612
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Type | Polymer |
| Capacitance | 390 µF |
| Tolerance | ±20% |
| Voltage - Rated | 2 V |
| ESR (Equivalent Series Resistance) | 10mOhm |
| Lifetime @ Temp. | 1000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Ratings | - |
| Applications | Bypass, Decoupling |
| Features | - |
| Ripple Current @ Low Frequency | - |
| Ripple Current @ High Frequency | 3.5 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | - |
| Size / Dimension | 0.287" L x 0.169" W (7.30mm x 4.30mm) |
| Height - Seated (Max) | 0.161" (4.10mm) |
| Surface Mount Land Size | 0.287" L x 0.169" W (7.30mm x 4.30mm) |
| Mounting Type | Surface Mount |
| Package / Case | 2917 (7343 Metric) |
ESRE391M02XB is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EEF-SX0D391XR | Panasonic Electronic Components | CAP ALUM POLY 390UF 20% 2V SMD | 100% | View |
| 2SW390MX | Rubycon | CAP ALUM POLY 390UF 20% 2V SMD | 100% | View |
| 875016219005 | Würth Elektronik | CAP ALUM POLY 390UF 20% 2V SMD | 88% | View |
| EEF-CX0D391R | Panasonic Electronic Components | CAP ALUM POLY 390UF 20% 2V SMD | 88% | View |
| EEF-SX0D391ER | Panasonic Electronic Components | CAP ALUM POLY 390UF 20% 2V SMD | 81% | View |
| EEF-SX0E391E4 | Panasonic Electronic Components | CAP ALUM POLY 390UF 20% 2.5V SMD | 62% | View |
Submit your RFQ for ESRE391M02XB and get a quote within 24 hours.
