Cornell Dubilier Electronics (CDE)
CAP ALUM 100UF 20% 25V SMD
AVEK107M25F24T-F is a Aluminum Electrolytic Capacitors manufactured by Cornell Dubilier Electronics (CDE). CAP ALUM 100UF 20% 25V SMD. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 105°C, voltage - rated 25 V, package / case Radial, Can - SMD.
In Stock: 2,689
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 100 µF |
| Tolerance | ±20% |
| Voltage - Rated | 25 V |
| ESR (Equivalent Series Resistance) | 2.7Ohm @ 120Hz |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 178 mA @ 120 Hz |
| Ripple Current @ High Frequency | 222.5 mA @ 10 kHz |
| Impedance | - |
| Lead Spacing | - |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Height - Seated (Max) | 0.394" (10.00mm) |
| Surface Mount Land Size | 0.331" L x 0.331" W (8.40mm x 8.40mm) |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
AVEK107M25F24T-F is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| VEU101M1ETR-0810S | Surge | CAP ALUM 25V POLAR | 82% | View |
| UUD1C101MCR1GS | Nichicon | CAP ALUM 100UF 20% 16V SMD | 75% | View |
| VZS101M1CTR-0606S | Surge | CAP ALUM 16V POLAR | 75% | View |
| VEJ101M1VTR-0810S | Surge | CAP ALUM 35V POLAR | 73% | View |
| VEH101M1ETR-0810S | Surge | CAP ALUM 25V POLAR | 66% | View |
| VEH101M1HTR-0810S | Surge | CAP ALUM 50V POLAR | 65% | View |
Submit your RFQ for AVEK107M25F24T-F and get a quote within 24 hours.
