Cornell Dubilier / Illinois Capacitor
330UF 4VDC 20% 7.3X4.3X1.9MM
337XMPL004MG19H is a Aluminum - Polymer Capacitors manufactured by Cornell Dubilier / Illinois Capacitor. 330UF 4VDC 20% 7.3X4.3X1.9MM. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 105°C, voltage - rated 4 V, package / case 2917 (7343 Metric).
In Stock: 6,122
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Polymer |
| Capacitance | 330 µF |
| Tolerance | ±20% |
| Voltage - Rated | 4 V |
| ESR (Equivalent Series Resistance) | 12mOhm |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Ratings | - |
| Applications | Decoupling |
| Features | - |
| Ripple Current @ Low Frequency | - |
| Ripple Current @ High Frequency | 2.7 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | - |
| Size / Dimension | 0.287" L x 0.169" W (7.30mm x 4.30mm) |
| Height - Seated (Max) | 0.083" (2.10mm) |
| Surface Mount Land Size | - |
| Mounting Type | Surface Mount |
| Package / Case | 2917 (7343 Metric) |
Submit your RFQ for 337XMPL004MG19H and get a quote within 24 hours.
