Cornell Dubilier / Illinois Capacitor
CAP ALUM 22UF 20% 100V RADIAL
226CKH100M is a Aluminum Electrolytic Capacitors manufactured by Cornell Dubilier / Illinois Capacitor. CAP ALUM 22UF 20% 100V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 100 V, package / case Radial, Can.
In Stock: 8,439
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 22 µF |
| Tolerance | ±20% |
| Voltage - Rated | 100 V |
| ESR (Equivalent Series Resistance) | 6.029Ohm @ 120Hz |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 150 mA @ 120 Hz |
| Ripple Current @ High Frequency | 345 mA @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.138" (3.50mm) |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Height - Seated (Max) | 0.512" (13.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| B41851A9226M006 | EPCOS - TDK Electronics | CAP ALUM 100V POLAR | 84% | View |
| 160LEX22MEFC10X12.5 | Rubycon | CAP ALUM 22UF 20% 160V RADIAL | 69% | View |
| 100YXF22MEFCT78X11.5 | Rubycon | CAP ALUM 22UF 20% 100V RADIAL | 69% | View |
| UPM1J220MED1TA | Nichicon | CAP ALUM 22UF 20% 63V RADIAL | 67% | View |
| MAL214262295E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 22UF 20% 350V RADIAL | 60% | View |
| 50ZL22MEFC5X11 | Rubycon | CAP ALUM 22UF 20% 50V RADIAL | 58% | View |
Submit your RFQ for 226CKH100M and get a quote within 24 hours.
