Cornell Dubilier / Illinois Capacitor
CAP ALUM POLY 150UF 20% 63V T/H
157ALG063MGBJ is a Aluminum - Polymer Capacitors manufactured by Cornell Dubilier / Illinois Capacitor. CAP ALUM POLY 150UF 20% 63V T/H. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 125°C, voltage - rated 63 V, package / case Radial, Can.
In Stock: 5,589
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Polymer |
| Capacitance | 150 µF |
| Tolerance | ±20% |
| Voltage - Rated | 63 V |
| ESR (Equivalent Series Resistance) | 25mOhm |
| Lifetime @ Temp. | 2000 Hrs @ 125°C |
| Operating Temperature | -55°C ~ 125°C |
| Ratings | - |
| Applications | Automotive |
| Features | - |
| Ripple Current @ Low Frequency | 145 mA @ 120 Hz |
| Ripple Current @ High Frequency | 2.9 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.394" Dia (10.00mm) |
| Height - Seated (Max) | 0.532" (13.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| A759MW157M1JAAE048 | KEMET | CAP ALUM POLY 150UF 20% 63V T/H | 95% | View |
| 157AVG035MFBJ | Cornell Dubilier / Illinois Capacitor | CAP ALUM POLY 150UF 20% 35V T/H | 81% | View |
| 157AVG025MFF | Cornell Dubilier / Illinois Capacitor | CAP ALUM POLY 150UF 20% 25V T/H | 79% | View |
| 157ALG035MFBJ | Cornell Dubilier / Illinois Capacitor | CAP ALUM POLY 150UF 20% 35V T/H | 75% | View |
| 6SEQP150M | Panasonic Electronic Components | CAP ALUM POLY 150UF 20% 6.3V T/H | 73% | View |
| PLX1C151MCL1TD | Nichicon | CAP ALUM POLY 150UF 20% 16V T/H | 61% | View |
