Cornell Dubilier / Illinois Capacitor
CAP ALUM 10000UF 20% 25V SNAP
109LBA025M2DC is a Aluminum Electrolytic Capacitors manufactured by Cornell Dubilier / Illinois Capacitor. CAP ALUM 10000UF 20% 25V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 85°C, voltage - rated 25 V, package / case Radial, Can - Snap-In.
In Stock: 5,223
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 10000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 25 V |
| ESR (Equivalent Series Resistance) | 74.6mOhm @ 120Hz |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 3.31 A @ 120 Hz |
| Ripple Current @ High Frequency | 4.1375 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.181" Dia (30.00mm) |
| Height - Seated (Max) | 1.063" (27.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| ESMH250VNN103MQ30U | United Chemi-Con | CAP ALUM 10000UF 20% 25V SNAP | 94% | View |
| MAL205846103E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 10000UF 20% 25V SNAP | 91% | View |
| B41505A7109M002 | EPCOS - TDK Electronics | CAP ALUM 10000UF 20% 35V SNAP | 82% | View |
| EKMH350VNN103MR35T | United Chemi-Con | CAP ALUM 10000UF 20% 35V SNAP | 80% | View |
| MAL205877103E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 10000UF 20% 40V SNAP | 73% | View |
| 380LQ103M063K042 | Cornell Dubilier Electronics (CDE) | CAP ALUM 10000UF 20% 63V SNAP | 58% | View |
Submit your RFQ for 109LBA025M2DC and get a quote within 24 hours.
