DC/DC CONVERTER 12V 750W
CFB750-300S12N-CMFD is a DC DC Converters manufactured by Cincon Electronics Co. LTD. DC/DC CONVERTER 12V 750W. Key specifications: mounting type Chassis Mount, operating temperature -40°C ~ 80°C (With Derating), current - output (max) 62.5A, size / dimension 9.45" L x 4.33" W x 1.65" H (240.0mm x 110.0mm x 41.9mm).
In Stock: 25
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Enclosed |
| Voltage - Input (Min) | 200V |
| Voltage - Input (Max) | 425V |
| Number of Outputs | 1 |
| Voltage - Output 1 | 12V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 62.5A |
| Power (Watts) | 750W |
| Voltage - Isolation | 3 kV |
| Applications | ITE (Commercial) |
| Efficiency | 88% |
| Operating Temperature | -40°C ~ 80°C (With Derating) |
| Mounting Type | Chassis Mount |
| Size / Dimension | 9.45" L x 4.33" W x 1.65" H (240.0mm x 110.0mm x 41.9mm) |
| Approval Agency | CE |
| Standard Number | 62368-1 |
Submit your RFQ for CFB750-300S12N-CMFD and get a quote within 24 hours.
