INDUCTOR CHOKE
AFDI00303012680M04 is a Fixed Inductors manufactured by Chilisin Electronics. INDUCTOR CHOKE. Key specifications: mounting type Through Hole, operating temperature -50°C ~ 155°C, package / case Radial, 3 Leads, current rating (amps) 12 A.
In Stock: 1,997
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Drum Core, Wirewound |
| Material - Core | Metal |
| Inductance | 68 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 12 A |
| Current - Saturation (Isat) | 11A |
| Shielding | Shielded |
| DC Resistance (DCR) | 27mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | AEC-Q200 |
| Operating Temperature | -50°C ~ 155°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, 3 Leads |
| Supplier Device Package | Radial - 3 Leads |
| Size / Dimension | 1.181" L x 1.181" W (30.00mm x 30.00mm) |
| Height - Seated (Max) | 0.500" (12.70mm) |
Submit your RFQ for AFDI00303012680M04 and get a quote within 24 hours.
