30MM FLUSH RED PUSHBUTTON 1 NC
PBO-FCRD-NC is a Pushbutton Switches manufactured by c3controls. 30MM FLUSH RED PUSHBUTTON 1 NC. Key specifications: mounting type Panel Mount, Rear, operating temperature -40°C ~ 55°C, voltage rating - dc 28 V, current rating (amps) 10A (AC), 5A (DC).
In Stock: 183
| Attribute | Value |
|---|---|
| Product Status | Active |
| Mounting Type | Panel Mount, Rear |
| Type | Standard |
| Circuit | SPST-NC |
| Switch Function | On-Mom |
| Current Rating (Amps) | 10A (AC), 5A (DC) |
| Voltage Rating - AC | 72 V |
| Voltage Rating - DC | 28 V |
| Actuator Type | Round, Button, Flush |
| Actuator Marking | No Marking |
| Color - Actuator/Cap | Red |
| Illumination Type, Color | - |
| Illumination Voltage (Nominal) | - |
| Termination Style | Screw Terminal |
| Ingress Protection | IP65 - Dust Tight, Water Resistant |
| Features | - |
| Panel Cutout Dimensions | Circular - 30.20mm Dia |
| Operating Temperature | -40°C ~ 55°C |
Submit your RFQ for PBO-FCRD-NC and get a quote within 24 hours.
