BXRC-65E4001-B-74 - Bridgelux - LED Lighting - COBs, Engines, Modules, Strips

BXRC-65E4001-B-74

Bridgelux

LED COB VERO 18 6500K ROUND

BXRC-65E4001-B-74 is a LED Lighting - COBs, Engines, Modules, Strips manufactured by Bridgelux. LED COB VERO 18 6500K ROUND. Key specifications: voltage - forward (vf) (typ) 34.1V, color White, Cool, current - max 1.8A, size / dimension 36.20mm Dia.

In Stock: 3,948

Product Attributes

AttributeValue
Product StatusActive
TypeChip On Board (COB)
ColorWhite, Cool
CCT (K)6500K 4-Step MacAdam Ellipse
Wavelength-
ConfigurationRound
Luminous Flux @ Current/Temperature4833lm (Typ)
Current - Test900mA
Temperature - Test85°C
Voltage - Forward (Vf) (Typ)34.1V
Lumens/Watt @ Current - Test157 lm/W
Current - Max1.8A
CRI (Color Rendering Index)80
Viewing Angle-
FeaturesWith Connector
Size / Dimension36.20mm Dia
Height1.90mm
Light Emitting Surface (LES)18.40mm Dia
Lens TypeFlat

Frequently Asked Questions

BXRC-65E4001-B-74 is a LED Lighting - COBs, Engines, Modules, Strips manufactured by Bridgelux. LED COB VERO 18 6500K ROUND

The supply voltage of BXRC-65E4001-B-74 is 34.1V.

The color of BXRC-65E4001-B-74 is White, Cool.

The current rating of BXRC-65E4001-B-74 is 1.8A.
