VERO 10C WARM WHITE LED ARRAY
BXRC-27H1000-C-72 is a LED Lighting - COBs, Engines, Modules, Strips manufactured by Bridgelux. VERO 10C WARM WHITE LED ARRAY. Key specifications: voltage - forward (vf) (typ) 34V, color White, Warm, current - max 720mA, size / dimension 20.00mm Dia.
In Stock: 4,834
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Chip On Board (COB) |
| Color | White, Warm |
| CCT (K) | 2700K 2-Step MacAdam Ellipse |
| Wavelength | - |
| Configuration | Starboard |
| Luminous Flux @ Current/Temperature | 1269lm (Typ) |
| Current - Test | 360mA |
| Temperature - Test | 85°C |
| Voltage - Forward (Vf) (Typ) | 34V |
| Lumens/Watt @ Current - Test | 104 lm/W |
| Current - Max | 720mA |
| CRI (Color Rendering Index) | 97 |
| Viewing Angle | 120° |
| Features | - |
| Size / Dimension | 20.00mm Dia |
| Height | 1.90mm |
| Light Emitting Surface (LES) | 9.90mm Dia |
| Lens Type | Flat |
