IND,6X5.7X4.8MM,22UH20%,3.4A,SHD
SRP5050FA-220M1 is a Fixed Inductors manufactured by Bourns Inc.. IND,6X5.7X4.8MM,22UH20%,3.4A,SHD. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 155°C, package / case Nonstandard, current rating (amps) 3.4 A.
In Stock: 923
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Drum Core, Wirewound |
| Material - Core | Metal |
| Inductance | 22 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 3.4 A |
| Current - Saturation (Isat) | 5A |
| Shielding | Shielded |
| DC Resistance (DCR) | 99.65mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | 8MHz |
| Ratings | AEC-Q200 |
| Operating Temperature | -55°C ~ 155°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.236" L x 0.224" W (6.00mm x 5.70mm) |
| Height - Seated (Max) | 0.197" (5.00mm) |
Submit your RFQ for SRP5050FA-220M1 and get a quote within 24 hours.
