FIXED IND 4.7UH 4.2A 54.1MOHM SM
SRP0520-4R7K is a Fixed Inductors manufactured by Bourns Inc.. FIXED IND 4.7UH 4.2A 54.1MOHM SM. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, package / case Nonstandard, current rating (amps) 4.2 A.
In Stock: 588
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | - |
| Material - Core | Metal |
| Inductance | 4.7 µH |
| Tolerance | ±10% |
| Current Rating (Amps) | 4.2 A |
| Current - Saturation (Isat) | 5.3A |
| Shielding | Shielded |
| DC Resistance (DCR) | 54.1mOhm Max |
| Q @ Freq | 18 @ 7.96MHz |
| Frequency - Self Resonant | 19MHz |
| Ratings | - |
| Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.213" L x 0.201" W (5.40mm x 5.10mm) |
| Height - Seated (Max) | 0.079" (2.00mm) |
Submit your RFQ for SRP0520-4R7K and get a quote within 24 hours.
