FIXED IND 1UH 7.5A 17.5 MOHM SMD
SRP0515-1R0K is a Fixed Inductors manufactured by Bourns Inc.. FIXED IND 1UH 7.5A 17.5 MOHM SMD. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, package / case Nonstandard, current rating (amps) 7.5 A.
In Stock: 7,293
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | - |
| Material - Core | Metal |
| Inductance | 1 µH |
| Tolerance | ±10% |
| Current Rating (Amps) | 7.5 A |
| Current - Saturation (Isat) | 10.6A |
| Shielding | Shielded |
| DC Resistance (DCR) | 17.5mOhm Max |
| Q @ Freq | 47 @ 7.96MHz |
| Frequency - Self Resonant | 42MHz |
| Ratings | - |
| Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.213" L x 0.201" W (5.40mm x 5.10mm) |
| Height - Seated (Max) | 0.059" (1.50mm) |
