FIXED IND 15UH 4.6A 45.5MOHM SMD
SRF1010DA-150M is a Fixed Inductors manufactured by Bourns Inc.. FIXED IND 15UH 4.6A 45.5MOHM SMD. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 155°C, package / case Nonstandard, current rating (amps) 4.6 A.
In Stock: 2,420
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Drum Core, Wirewound |
| Material - Core | Metal |
| Inductance | 15 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 4.6 A |
| Current - Saturation (Isat) | 5.5A |
| Shielding | Shielded |
| DC Resistance (DCR) | 45.5mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | 10MHz |
| Ratings | AEC-Q200 |
| Operating Temperature | -55°C ~ 155°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.472" L x 0.378" W (12.00mm x 9.60mm) |
| Height - Seated (Max) | 0.457" (11.60mm) |
Submit your RFQ for SRF1010DA-150M and get a quote within 24 hours.
