INDUCT ARRAY 2 COIL 2.2UH SMD
SRF0703-2R2M is a Arrays, Signal Transformers manufactured by Bourns Inc.. INDUCT ARRAY 2 COIL 2.2UH SMD. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, package / case Nonstandard, size / dimension 0.299" L x 0.299" W (7.60mm x 7.60mm).
In Stock: 1,825
| Attribute | Value |
|---|---|
| Product Status | Active |
| Number of Coils | 2 |
| Inductance - Connected In Parallel | 2.2 µH |
| Inductance - Connected In Series | 8.8 µH |
| Tolerance | ±20% |
| Current Rating - Parallel | 4.11 A |
| Current Rating - Series | 2.06 A |
| Current Saturation - Parallel | 5.52 A |
| Current Saturation - Series | 2.76 A |
| DC Resistance (DCR) - Parallel | 21.7mOhm Max |
| DC Resistance (DCR) - Series | 132mOhm Max |
| Shielding | Shielded |
| Ratings | - |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Size / Dimension | 0.299" L x 0.299" W (7.60mm x 7.60mm) |
| Height | 0.142" (3.60mm) |
