INDUCT ARRAY 6 COIL 11.6UH SMD
PM610-05-RC is a Arrays, Signal Transformers manufactured by Bourns Inc.. INDUCT ARRAY 6 COIL 11.6UH SMD. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 105°C, package / case 12-SMD, Gull Wing, size / dimension 0.591" L x 0.630" W (15.00mm x 16.00mm).
In Stock: 2,193
| Attribute | Value |
|---|---|
| Product Status | Active |
| Number of Coils | 6 |
| Inductance - Connected In Parallel | 11.6 µH |
| Inductance - Connected In Series | 417.6 µH |
| Tolerance | ±10% |
| Current Rating - Parallel | 4.08 A |
| Current Rating - Series | 680 mA |
| Current Saturation - Parallel | 7.8 A |
| Current Saturation - Series | 1.3 A |
| DC Resistance (DCR) - Parallel | 34mOhm |
| DC Resistance (DCR) - Series | 1.212Ohm |
| Shielding | Unshielded |
| Ratings | - |
| Operating Temperature | -40°C ~ 105°C |
| Mounting Type | Surface Mount |
| Package / Case | 12-SMD, Gull Wing |
| Size / Dimension | 0.591" L x 0.630" W (15.00mm x 16.00mm) |
| Height | 0.307" (7.80mm) |
Submit your RFQ for PM610-05-RC and get a quote within 24 hours.
