PCS020-EE05980S - Bourns Inc. - Current Sense Transformers

PCS020-EE05980S

Bourns Inc.

CURRENT SENSE TRANSF 20A 980UH

PCS020-EE05980S is a Current Sense Transformers manufactured by Bourns Inc.. CURRENT SENSE TRANSF 20A 980UH. Key specifications: mounting type Surface Mount, current rating (amps) 20 A, size / dimension 0.245" L x 0.235" W (6.22mm x 5.97mm), termination style Gull Wing.

In Stock: 2,930

Product Attributes

AttributeValue
Product StatusActive
Frequency Range1MHz
TypeInvasive
Current Rating (Amps)20 A
Inductance980 mH
ET (Volt-Time)37.8VµS
Turns Ratio - Primary:Secondary1:70
Current Ratio70:1
DC Resistance (DCR)7mOhm Primary, 4.75Ohm Secondary Max
Ratings-
Mounting TypeSurface Mount
Size / Dimension0.245" L x 0.235" W (6.22mm x 5.97mm)
Height - Seated (Max)0.209" (5.31mm)
Termination StyleGull Wing

Frequently Asked Questions

PCS020-EE05980S is a Current Sense Transformers manufactured by Bourns Inc.. CURRENT SENSE TRANSF 20A 980UH

The mounting type of PCS020-EE05980S is Surface Mount.

The current rating of PCS020-EE05980S is 20 A.

The size of PCS020-EE05980S is 0.245" L x 0.235" W (6.22mm x 5.97mm).
