CURRENT SENSE TRANSF 20A 500UH
PCS020-EE05500S is a Current Sense Transformers manufactured by Bourns Inc.. CURRENT SENSE TRANSF 20A 500UH. Key specifications: mounting type Surface Mount, current rating (amps) 20 A, size / dimension 0.245" L x 0.235" W (6.22mm x 5.97mm), termination style Gull Wing.
In Stock: 6,561
| Attribute | Value |
|---|---|
| Product Status | Active |
| Frequency Range | 1MHz |
| Type | Invasive |
| Current Rating (Amps) | 20 A |
| Inductance | 500 mH |
| ET (Volt-Time) | 27VµS |
| Turns Ratio - Primary:Secondary | 1:50 |
| Current Ratio | 50:1 |
| DC Resistance (DCR) | 7mOhm Primary, 1.5Ohm Secondary Max |
| Ratings | - |
| Mounting Type | Surface Mount |
| Size / Dimension | 0.245" L x 0.235" W (6.22mm x 5.97mm) |
| Height - Seated (Max) | 0.209" (5.31mm) |
| Termination Style | Gull Wing |
Submit your RFQ for PCS020-EE05500S and get a quote within 24 hours.
