LED RGB CLEAR 6PLCC SMD
SMTL6-RGB is a LED Indication - Discrete manufactured by Bivar Inc.. LED RGB CLEAR 6PLCC SMD. Key specifications: mounting type Surface Mount, voltage - forward (vf) (typ) 1.8V Red, 3V Green, 3V Blue, package / case 6-SMD, J-Lead, color Red, Green, Blue (RGB).
In Stock: 130
| Attribute | Value |
|---|---|
| Product Status | Active |
| Color | Red, Green, Blue (RGB) |
| Configuration | Independent |
| Lens Color | Colorless |
| Lens Transparency | Clear |
| Millicandela Rating | 600mcd Red, 800mcd Green, 350mcd Blue |
| Lens Style | Round with Flat Top |
| Lens Size | 4.00mm Dia |
| Voltage - Forward (Vf) (Typ) | 1.8V Red, 3V Green, 3V Blue |
| Current - Test | 20mA Red, 20mA Green, 20mA Blue |
| Viewing Angle | 140° |
| Mounting Type | Surface Mount |
| Wavelength - Dominant | 626nm Red, 526nm Green, 471nm Blue |
| Wavelength - Peak | - |
| Features | - |
| Package / Case | 6-SMD, J-Lead |
| Supplier Device Package | 6-PLCC |
| Size / Dimension | 5.40mm L x 5.00mm W |
| Height (Max) | 1.60mm |
