AC/DC CONVERTER 12V 50W
LOK4301-2RG is a Industrial, DIN Rail Power Supplies manufactured by Bel Power Solutions. AC/DC CONVERTER 12V 50W. Key specifications: operating temperature -10°C ~ 70°C (With Derating), current - output (max) 4A, size / dimension 4.47" L x 1.50" W x 3.54" H (113.6mm x 38.0mm x 90.0mm), number of outputs 1.
In Stock: 13
| Attribute | Value |
|---|---|
| Product Status | Active |
| Input Type | AC |
| Number of Outputs | 1 |
| AC Voltage - Input | 85 ~ 264 VAC |
| DC Voltage - Input (Min) | - |
| DC Voltage - Input (Max) | - |
| Voltage - Output 1 | 12V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Voltage - Output 5 | - |
| Voltage - Output 6 | - |
| Current - Output (Max) | 4A |
| Power (Watts) | 50W |
| Voltage - Isolation | 4.3 kV |
| Applications | ITE (Commercial) |
| Efficiency | 82% |
| Operating Temperature | -10°C ~ 70°C (With Derating) |
| Features | Adjustable Output, Load Sharing, Universal Input |
| Size / Dimension | 4.47" L x 1.50" W x 3.54" H (113.6mm x 38.0mm x 90.0mm) |
| Approval Agency | cCSAus, CE, cULus, NEMKO, TUV |
| Standard Number | - |
