AC/DC CONVERTER 48V 480W
LDW480-48 is a Industrial, DIN Rail Power Supplies manufactured by Bel Power Solutions. AC/DC CONVERTER 48V 480W. Key specifications: operating temperature -40°C ~ 70°C (With Derating), current - output (max) 10A, size / dimension 4.92" L x 2.87" W x 5.51" H (125.0mm x 73.0mm x 140.0mm), number of outputs 1.
In Stock: 8
| Attribute | Value |
|---|---|
| Product Status | Active |
| Input Type | AC or DC |
| Number of Outputs | 1 |
| AC Voltage - Input | 187 ~ 550 VAC (1 ~ 2 Phase) |
| DC Voltage - Input (Min) | 250V |
| DC Voltage - Input (Max) | 725V |
| Voltage - Output 1 | 48V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Voltage - Output 5 | - |
| Voltage - Output 6 | - |
| Current - Output (Max) | 10A |
| Power (Watts) | 480W |
| Voltage - Isolation | 4.2 kV |
| Applications | ITE (Commercial) |
| Efficiency | 92% |
| Operating Temperature | -40°C ~ 70°C (With Derating) |
| Features | Adjustable Output, IP20, PFC |
| Size / Dimension | 4.92" L x 2.87" W x 5.51" H (125.0mm x 73.0mm x 140.0mm) |
| Approval Agency | - |
| Standard Number | - |
Submit your RFQ for LDW480-48 and get a quote within 24 hours.
