DIMENSION=38 X 127 X 120 MM, VER
BAE00T4 is a Industrial, DIN Rail Power Supplies manufactured by Balluff. DIMENSION=38 X 127 X 120 MM, VER. Key specifications: operating temperature -25°C ~ 70°C (With Derating), current - output (max) 7.5A, size / dimension 4.53" L x 1.50" W x 5.00" H (115.0mm x 38.0mm x 127.0mm), number of outputs 1.
In Stock: 4
| Attribute | Value |
|---|---|
| Product Status | Active |
| Input Type | AC |
| Number of Outputs | 1 |
| AC Voltage - Input | 90 ~ 132 VAC, 198 ~ 264 VAC |
| DC Voltage - Input (Min) | - |
| DC Voltage - Input (Max) | - |
| Voltage - Output 1 | 24V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Voltage - Output 5 | - |
| Voltage - Output 6 | - |
| Current - Output (Max) | 7.5A |
| Power (Watts) | 180W |
| Voltage - Isolation | 3 kV |
| Applications | ITE (Commercial) |
| Efficiency | 92% |
| Operating Temperature | -25°C ~ 70°C (With Derating) |
| Features | Adjustable Output, IP20, Universal Input |
| Size / Dimension | 4.53" L x 1.50" W x 5.00" H (115.0mm x 38.0mm x 127.0mm) |
| Approval Agency | CE, cULus, cURus |
| Standard Number | - |
Submit your RFQ for BAE00T4 and get a quote within 24 hours.
