DUAL 8-CH ANALOG MULTIPLEXER
MUX28FPC is a Interface - Analog Switches, Multiplexers, Demultiplexers manufactured by Analog Devices Inc.. DUAL 8-CH ANALOG MULTIPLEXER. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 85°C, package / case 28-CDIP (0.600", 15.24mm), number of circuits 2.
In Stock: 4,999
| Attribute | Value |
|---|---|
| Product Status | Active |
| Switch Circuit | - |
| Multiplexer/Demultiplexer Circuit | 8:1 |
| Number of Circuits | 2 |
| On-State Resistance (Max) | 800Ohm |
| Channel-to-Channel Matching (ΔRon) | 5Ohm |
| Voltage - Supply, Single (V+) | ±15V |
| Voltage - Supply, Dual (V±) | ±15V |
| Switch Time (Ton, Toff) (Max) | 2µs, 500ns |
| -3db Bandwidth | - |
| Charge Injection | - |
| Channel Capacitance (CS(off), CD(off)) | 2.5pF, 8pF |
| Current - Leakage (IS(off)) (Max) | 1nA |
| Crosstalk | -70dB @ 100kHz |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Through Hole |
| Package / Case | 28-CDIP (0.600", 15.24mm) |
| Supplier Device Package | 28-CDIP |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MUX28FP | Analog Devices Inc. | DUAL 8-CH ANALOG MULTIPLEXER | 100% | View |
| 5962-8771801EA | Analog Devices Inc. | ANALOG MUX DUAL 4:1 (MUX-24A) | 100% | View |
| MUX24AQ/883C | Analog Devices Inc. | DUAL 4-CH ANALOG MULTIPLEXER | 100% | View |
| 5962-8771701XA | Analog Devices Inc. | 16-CHANNEL ANALOG MULTIPLEXER | 89% | View |
| MUX16AT/883C | Analog Devices Inc. | 16-CH JFET ANALOG MULTIPLEXERS | 89% | View |
| 5962-8771602EA | Analog Devices Inc. | IC 8CH JFET MUX/DEMUX 16CDIP | 78% | View |
Submit your RFQ for MUX28FPC and get a quote within 24 hours.
