DGT ISO 5000VRMS 2CH LVDS 20SOIC
ADN4656BRWZ is a Digital Isolators manufactured by Analog Devices Inc.. DGT ISO 5000VRMS 2CH LVDS 20SOIC. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, voltage - supply 2.375V ~ 2.625V, package / case 20-SOIC (0.295", 7.50mm Width).
In Stock: 5,410
| Attribute | Value |
|---|---|
| Product Status | Active |
| Technology | Magnetic Coupling |
| Type | LVDS |
| Isolated Power | No |
| Number of Channels | 2 |
| Inputs - Side 1/Side 2 | 1/1 |
| Channel Type | Unidirectional |
| Voltage - Isolation | 5000Vrms |
| Common Mode Transient Immunity (Min) | 25kV/µs |
| Data Rate | 1.1Gbps |
| Propagation Delay tpLH / tpHL (Max) | 4.5ns, 4.5ns |
| Pulse Width Distortion (Max) | - |
| Rise / Fall Time (Typ) | 0.35ns, 0.35ns (Max) |
| Voltage - Supply | 2.375V ~ 2.625V |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 20-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 20-SOIC |
Submit your RFQ for ADN4656BRWZ and get a quote within 24 hours.
