IC ADC 16BIT SAR 32BBDIP
AD1380JD is a Data Acquisition - Analog to Digital Converters (ADC) manufactured by Analog Devices Inc.. IC ADC 16BIT SAR 32BBDIP. Key specifications: mounting type Through Hole, operating temperature 0°C ~ 70°C, voltage - supply, digital 5V, package / case 32-CDIP (0.900", 22.86mm).
In Stock: 52
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Number of Bits | 16 |
| Sampling Rate (Per Second) | 50k |
| Number of Inputs | 16 |
| Input Type | Single Ended |
| Data Interface | Parallel |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | Internal |
| Voltage - Supply, Analog | ±14.5V ~ 15.5V |
| Voltage - Supply, Digital | 5V |
| Features | - |
| Operating Temperature | 0°C ~ 70°C |
| Package / Case | 32-CDIP (0.900", 22.86mm) |
| Supplier Device Package | 32-BBDIP-H |
| Mounting Type | Through Hole |
AD1380JD is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| ADADC85Z-12 | Analog Devices Inc. | 12-BIT SAR PARALLEL ADC | 90% | View |
| ADADC84Z-12 | Analog Devices Inc. | 12-BIT SAR PARALLEL ADC | 90% | View |
| AD9034TD/883B | Analog Devices Inc. | SINGLE ADC PIPELINED 20MSPS 12 B | 88% | View |
| AD9023BQ | Analog Devices Inc. | 12-BIT ADC, PARALLEL WORD ACCESS | 65% | View |
| AD9023BZ | Analog Devices Inc. | 12-BIT ADC, PARALLEL WORD ACCESS | 65% | View |
| AD9023AQ | Analog Devices Inc. | 12-BIT ADC, PARALLEL WORD ACCESS | 65% | View |
Submit your RFQ for AD1380JD and get a quote within 24 hours.
