Analog Devices Inc./Maxim Integrated
IC 2-CHL DIGITAL ISOLATOR SOIC
MAX22519AWA+ is a Digital Isolators manufactured by Analog Devices Inc./Maxim Integrated. IC 2-CHL DIGITAL ISOLATOR SOIC. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, voltage - supply 3V ~ 5.5V, package / case 8-SOIC (0.209", 5.30mm Width).
In Stock: 1,120
| Attribute | Value |
|---|---|
| Product Status | Active |
| Technology | Capacitive Coupling |
| Type | General Purpose |
| Isolated Power | No |
| Number of Channels | 2 |
| Inputs - Side 1/Side 2 | 2/0 |
| Channel Type | Unidirectional |
| Voltage - Isolation | 3500Vrms |
| Common Mode Transient Immunity (Min) | 50kV/µs |
| Data Rate | 1Mbps |
| Propagation Delay tpLH / tpHL (Max) | 130ns, 130ns |
| Pulse Width Distortion (Max) | 20ns |
| Rise / Fall Time (Typ) | 20ns, 20ns |
| Voltage - Supply | 3V ~ 5.5V |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.209", 5.30mm Width) |
| Supplier Device Package | 8-SOIC |
Submit your RFQ for MAX22519AWA+ and get a quote within 24 hours.
