5MM RED&GREEN BI-COLOR LED LAMP
L517GYW is a LED Indication - Discrete manufactured by American Opto Plus LED. 5MM RED&GREEN BI-COLOR LED LAMP. Key specifications: mounting type Through Hole, voltage - forward (vf) (typ) 2.1V Green, 2.1V Yellow, package / case Radial, color Green, Yellow.
In Stock: 3,900
| Attribute | Value |
|---|---|
| Product Status | Active |
| Color | Green, Yellow |
| Configuration | - |
| Lens Color | White |
| Lens Transparency | Diffused |
| Millicandela Rating | 15mcd Green, 15mcd Yellow |
| Lens Style | Round with Domed Top |
| Lens Size | 5mm, T-1 3/4 |
| Voltage - Forward (Vf) (Typ) | 2.1V Green, 2.1V Yellow |
| Current - Test | 30mA Green, 30mA Yellow |
| Viewing Angle | 60° |
| Mounting Type | Through Hole |
| Wavelength - Dominant | 565nm Green, 585nm Yellow |
| Wavelength - Peak | - |
| Features | - |
| Package / Case | Radial |
| Supplier Device Package | - |
| Size / Dimension | 5.00mm Dia |
| Height (Max) | 9.60mm |
Submit your RFQ for L517GYW and get a quote within 24 hours.
