Allied Components International
330H 30% POWER CHIP SHIELDED
PCS105-331T-RC is a Fixed Inductors manufactured by Allied Components International. 330H 30% POWER CHIP SHIELDED. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 125°C, package / case Nonstandard, size / dimension 0.413" L x 0.406" W (10.50mm x 10.30mm).
In Stock: 780
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | - |
| Material - Core | - |
| Inductance | 330 µH |
| Tolerance | ±30% |
| Current Rating (Amps) | - |
| Current - Saturation (Isat) | 750mA |
| Shielding | Shielded |
| DC Resistance (DCR) | 812mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -55°C ~ 125°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.413" L x 0.406" W (10.50mm x 10.30mm) |
| Height - Seated (Max) | 0.197" (5.00mm) |
Submit your RFQ for PCS105-331T-RC and get a quote within 24 hours.
