FIXED IND 27NH 250MA 2.35OHM SMD
ATFC-0603-27N-FT is a Fixed Inductors manufactured by Abracon LLC. FIXED IND 27NH 250MA 2.35OHM SMD. Key specifications: mounting type Surface Mount, operating temperature -25°C ~ 85°C, package / case 0603 (1608 Metric), current rating (amps) 250 mA.
In Stock: 6,854
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Type | Thin Film |
| Material - Core | Ceramic |
| Inductance | 27 nH |
| Tolerance | ±1% |
| Current Rating (Amps) | 250 mA |
| Current - Saturation (Isat) | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 2.35Ohm Max |
| Q @ Freq | 15 @ 300MHz |
| Frequency - Self Resonant | 2GHz |
| Ratings | - |
| Operating Temperature | -25°C ~ 85°C |
| Inductance Frequency - Test | 300 MHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | 0603 (1608 Metric) |
| Supplier Device Package | 0603 (1608 Metric) |
| Size / Dimension | 0.063" L x 0.031" W (1.60mm x 0.80mm) |
| Height - Seated (Max) | 0.022" (0.55mm) |
Submit your RFQ for ATFC-0603-27N-FT and get a quote within 24 hours.
