FIXED IND 3.3UH 5.5A 36MOHM SMD
AMDLA4530S-3R3MT is a Fixed Inductors manufactured by Abracon LLC. FIXED IND 3.3UH 5.5A 36MOHM SMD. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 155°C, package / case Nonstandard, current rating (amps) 5.5 A.
In Stock: 995
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Molded |
| Material - Core | Metal |
| Inductance | 3.3 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 5.5 A |
| Current - Saturation (Isat) | 5A |
| Shielding | Shielded |
| DC Resistance (DCR) | 36mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -55°C ~ 155°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.193" L x 0.185" W (4.90mm x 4.70mm) |
| Height - Seated (Max) | 0.118" (3.00mm) |
Submit your RFQ for AMDLA4530S-3R3MT and get a quote within 24 hours.
