CF87 SERIES 0.50MM(.020") ZIF SI
CF8720WH0R0-05-NH is a FFC, FPC (Flat Flexible) Connectors manufactured by Cvilux USA. CF87 SERIES 0.50MM(.020") ZIF SI. Key specifications: mounting type Surface Mount, Right Angle, housing material Thermoplastic, Halogen Free, termination Solder, number of positions 20.
In Stock: 3,440
| Attribute | Value |
|---|---|
| Product Status | Active |
| Flat Flex Type | FFC, FPC |
| Mounting Type | Surface Mount, Right Angle |
| Connector/Contact Type | Contacts, Top and Bottom |
| Number of Positions | 20 |
| Pitch | 0.020" (0.50mm) |
| Termination | Solder |
| FFC, FCB Thickness | 0.30mm |
| Height Above Board | 0.039" (1.00mm) |
| Locking Feature | Flip Lock, Backlock |
| Cable End Type | Notched |
| Contact Material | Phosphor Bronze |
| Contact Finish | - |
| Housing Material | Thermoplastic, Halogen Free |
| Actuator Material | Thermoplastic, Halogen Free |
| Features | Solder Retention, Zero Insertion Force (ZIF) |
| Voltage Rating | - |
| Operating Temperature | - |
| Material Flammability Rating | UL94 V-0 |
Submit your RFQ for CF8720WH0R0-05-NH and get a quote within 24 hours.
