Alpha & Omega Semiconductor Inc.
IC USB 2.0 SWITCH 6DFN
AOZ6134DI is a Interface - Analog Switches, Multiplexers, Demultiplexers manufactured by Alpha & Omega Semiconductor Inc.. IC USB 2.0 SWITCH 6DFN. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 85°C (TA), package / case 6-UFDFN, number of circuits 1.
In Stock: 4,795
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Switch Circuit | SPDT |
| Multiplexer/Demultiplexer Circuit | - |
| Number of Circuits | 1 |
| On-State Resistance (Max) | 1.2Ohm |
| Channel-to-Channel Matching (ΔRon) | 30mOhm |
| Voltage - Supply, Single (V+) | 1.65V ~ 5.5V |
| Voltage - Supply, Dual (V±) | - |
| Switch Time (Ton, Toff) (Max) | 55ns, 45ns |
| -3db Bandwidth | 180MHz |
| Charge Injection | 90pC |
| Channel Capacitance (CS(off), CD(off)) | 7pF |
| Current - Leakage (IS(off)) (Max) | 30nA |
| Crosstalk | -60dB @ 1MHz |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 6-UFDFN |
| Supplier Device Package | 6-DFN (1.2x1.1) |
AOZ6134DI is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| AOZ6134DI#A | Alpha & Omega Semiconductor Inc. | IC USB 2.0 SWITCH 6DFN | 100% | View |
| 74HC4351DB,118 | Nexperia USA Inc. | IC MUX/DEMUX 8X1 20SSOP | 81% | View |
| 74HC4351PWJ | Nexperia USA Inc. | IC MUX/DEMUX 8X1 20TSSOP | 81% | View |
| DG408LDQ-T1-E3 | Vishay Siliconix | IC MUX CMOS ANG DUAL 8CH 16TSSOP | 74% | View |
| FSA5157L6X | onsemi | IC SWITCH SPDT 6MICROPAK | 57% | View |
| FSA2156L6X | Fairchild Semiconductor | LOW VOLTAGE SPST 0.4 OHM ANALOG | 53% | View |
